The location of creepmeter MEJ3 is situated 1.6 km south of Creepmeter MEJ2. The instrument was installed across the same active branch of the Mejillones Fault. It was installed directly in a paleoseismological trench where the location of the active branch could be well determined. Similar to the MEJ2 site multiple normal fault reactivation is documented in the trench. The active fault plane strikes 199° and dips 78° E.
Location | -22.842333° S/ -70.183200° W |
Elevation | 1077 m |
Installation Date | 2009/04/06 |
Azimuth | 75° |
Dip | 5° |
Length | 5 m |
Depth | 90 cm |
Sampling Rate | 60 sec, 30 sec since June 2010 |
Modifications | 2009/11/18 logger exchange and GPS antenna installation for time synchronization 2010/06/08 logger power supply connected to battery, 1 V reference signal, adjustment internal clock, increased sampling rate to 30 sec 2010/10/18 setup online connection 2010/10/31 logger firmware update 2011/04/01 differential voltage measurement installation of temperature reference sensor (Pt100), installation box temperature sensor, LVDT power supply connected directly to battery 2011/11/08 logger firmware update |
